M60T Sabra
Type: Main Battle Tank
Domain: land
Country of Origin: Türkiye
Manufacturer: IMI Systems (Israel) / FNSS (Turkey)
First Deployed: 2007
Overview
The M60T Sabra is an extensively modernized version of the M60A1 MBT, upgraded by Israeli Military Industries (IMI) for the Turkish Army. Key upgrades include a new 120mm smoothbore gun replacing the original 105mm rifled barrel, a modern fire control system with thermal imager and laser rangefinder, and a modular composite/reactive armor package. Approximately 170 Sabras are in service, providing the Turkish Army with a capable heavy armor force to complement the Leopard 2A4 fleet until the domestic Altay MBT is delivered in sufficient numbers.
Technical Specifications
| crew | 4 |
|---|---|
| armor | TISAS composite add-on + ROMOR-A ERA |
| engine | MTU-833 Ka-501 diesel, 1,000 hp |
| width_m | 3.6 |
| height_m | 2.6 |
| length_m | 9.9 |
| main_gun | 120mm Rheinmetall L44 smoothbore |
| range_km | 450 |
| secondary | M240 7.62mm coaxial + M2HB 12.7mm |
| fire_control | ELOP Knight thermal sight |
| max_speed_kmh | 55 |
| weight_tonnes | 59 |
Operators
- Bahrain
- Türkiye
