HJ-8 ATGM
Type: Anti-Tank Guided Missile
Domain: land
Country of Origin: China
Manufacturer: NORINCO (China North Industries)
First Deployed: 2005
Overview
The HJ-8 (Red Arrow-8) is a Chinese wire-guided anti-tank missile system developed by Norinco, using SACLOS (Semi-Automatic Command to Line of Sight) guidance. The HJ-8E variant carries a tandem HEAT warhead that penetrates over 800mm of rolled homogeneous armor after defeating explosive reactive armor, providing adequate anti-tank capability against most regional threats. Bangladesh operates the HJ-8 as a cost-effective man-portable and vehicle-mounted anti-armor system for infantry formations, providing a standoff capability against armored threats at ranges up to 4 km.
Technical Specifications
| length | 1.2 m |
|---|---|
| weight | 24.5 kg (missile + launcher) |
| warhead | Tandem HEAT, 800mm+ RHAe penetration (HJ-8E) |
| guidance | Wire-guided SACLOS |
| platform | Tripod or vehicle-mounted |
| velocity | 220 m/s |
| range_max | 4,000 m |
| range_min | 100 m |
Operators
- Bangladesh
- China
- Pakistan
- Various
