Sea Fire Radar
Type: Radar System
Domain: sea
Country of Origin: France
Manufacturer: Thales
Overview
Revolutionary four-panel fixed-array S-band AESA (Active Electronically Scanned Array) multifunction radar designed for the FDI Belharra frigate class. Provides simultaneous 360-degree surveillance, tracking, missile guidance, and horizon search with no mechanical rotation — a first for a European surface combatant radar of this class. Features GaN (Gallium Nitride) transmit/receive modules for high power output and reliability. Capable of detecting and tracking air, surface, and ballistic missile threats with fire-control quality tracks. Each fixed panel covers a 90-degree sector with electronic beam steering providing instantaneous sector coverage. Replaces the traditional rotating radar paradigm with a fully digital, software-defined architecture.
Technical Specifications
| band | S-band |
|---|---|
| note | Sea Fire 500 equipped on FDI Belharra and Kimon class frigates |
| type | Active Digital AESA Radar |
| faces | 4 |
| weight_tonnes | 15 |
| range_km_missile | 200 |
| range_km_aircraft | 400 |
| simultaneous_tracks | 1000 |
| simultaneous_engagements | 16 |
Operators
- France
- Greece
