M4A1 Carbine
Type: Assault Rifle
Domain: land
Country of Origin: United States
Manufacturer: FN Herstal
Overview
Standard issue 5.56x45mm NATO carbine of the US military since the 1990s. Gas-operated, air-cooled, magazine-fed with selective fire including full-auto capability. Over 500,000 in US service. Being gradually replaced by the M7 for close combat forces but will remain in service with support and non-combat units for decades.
Technical Specifications
| Type | Assault Carbine |
|---|---|
| Length | 838 mm (stock extended) / 757 mm (collapsed) |
| Weight | 2.88 kg (empty) |
| Caliber | 5.56x45mm NATO |
| Magazine | 30-round STANAG |
| Rate of Fire | 750-900 rpm (M4A1: full-auto capable) |
| Barrel Length | 368 mm |
| Effective Range | 500 m (point) / 600 m (area) |
| Muzzle Velocity | 884 m/s |
Operators
- Afghanistan
- Australia
- Canada
- Iraq
- Israel
- Philippines
- United Kingdom
- United States
